Standard name
Description Conserved NADPH oxidoreductase containing flavin mononucleotide (FMN); responsible for geraniol reduction into citronellol during fermentation; homologous to Oye3p with different ligand binding and catalytic properties; may be involved in sterol metabolism, oxidative stress response, and programmed cell death; protein abundance increases in response to DNA replication stress

Micrographs

ensLOC DeepLoc
Localization WT1 WT2 WT3 RAP60 RAP140 RAP220 RAP300 RAP380 RAP460 RAP540 RAP620 RAP700 HU80 HU120 HU160 rpd3Δ_1 rpd3Δ_2 rpd3Δ_3 WT1 WT2 WT3 AF100 AF140 AF180
Cortical Patches 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bud 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bud Neck 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bud Site 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Cell Periphery 0 0 0.05 0 0 0 0.06 0.07 0.09 0 0 0.06 0 0 0 0 0 0 0 0 0 0 0 0
Cytoplasm 1.0 1.0 0.99 1.0 0.96 0.97 0.92 0.89 0.87 0.86 0.88 0.92 0.99 0.99 1.0 1.0 0.99 1.0 0.93 0.94 0.97 0.92 0.93 0.94
Endoplasmic Reticulum 0 0 0 0 0 0 0.06 0.08 0.08 0.11 0.07 0.06 0 0 0 0.05 0.05 0 0 0 0 0 0 0
Endosome 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Golgi 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mitochondria 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Nucleus 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0.05 0 0
Nuclear Periphery 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Nucleolus 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Peroxisomes 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SpindlePole 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Vac/Vac Membrane 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ensLOC DeepLoc
Localization WT1 WT2 WT3 RAP60 RAP140 RAP220 RAP300 RAP380 RAP460 RAP540 RAP620 RAP700 HU80 HU120 HU160 rpd3Δ_1 rpd3Δ_2 rpd3Δ_3 WT1 WT2 WT3 AF100 AF140 AF180
Cortical Patches 0 0 0 0 0 0 0 1 0 2 2 1 0 0 0 0 0 0 0 0 0 0 0 0
Bud 0 1 1 0 4 4 1 4 2 3 6 2 1 0 0 0 0 0 1 2 1 0 3 4
Bud Neck 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bud Site 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Cell Periphery 0 1 19 4 6 12 29 34 38 20 15 21 7 5 2 4 1 1 0 0 0 0 0 0
Cytoplasm 37 145 351 229 306 361 443 439 363 393 319 336 207 249 258 209 138 117 52 136 330 27 168 219
Endoplasmic Reticulum 0 0 1 1 8 6 29 40 33 51 27 21 2 1 0 10 7 5 0 1 3 0 0 0
Endosome 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Golgi 0 0 0 0 0 1 0 0 0 0 2 0 0 0 0 0 0 0 0 0 0 0 0 0
Mitochondria 1 0 0 0 0 0 0 0 0 1 1 2 0 0 0 0 0 1 0 0 0 0 0 0
Nucleus 0 0 2 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 3 0
Nuclear Periphery 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
Nucleolus 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Peroxisomes 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SpindlePole 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Vac/Vac Membrane 0 0 1 0 4 0 0 1 0 0 1 1 0 1 0 0 3 0 0 2 1 0 1 2
Unique Cell Count 37 145 354 230 319 372 483 493 415 456 361 367 209 251 258 210 140 117 57 146 340 30 180 232
Labelled Cell Count 38 147 375 234 328 384 502 519 436 470 373 384 217 256 260 223 149 124 57 146 340 30 180 232


Cytoplasm, Nucleus

(Huh et al. Nature 2003 425:686)
Screen WT1 WT2 WT3 RAP60 RAP140 RAP220 RAP300 RAP380 RAP460 RAP540 RAP620 RAP700 HU80 HU120 HU160 rpd3Δ_1 rpd3Δ_2 rpd3Δ_3 AF100 AF140 AF180
Mean Cell GFP Intensity (1e-4) 45.6 62.0 50.0 49.6 44.3 52.6 53.3 55.4 53.7 50.6 51.5 50.0 49.4 53.8 57.1 118.2 110.6 114.4 43.5 50.1
Std Deviation (1e-4) 15.3 18.5 11.3 13.7 15.3 13.2 13.0 13.6 14.1 12.7 13.2 13.1 12.8 17.2 15.9 39.2 48.3 39.8 15.2 15.6
Intensity Change (Log2) -0.01 -0.18 0.07 0.09 0.15 0.1 0.02 0.04 -0.0 -0.02 0.11 0.19 1.24 1.14 1.19 -0.2 0.0


Localization RAP60 RAP140 RAP220 RAP300 RAP380 RAP460 RAP540 RAP620 RAP700 HU80 HU120 HU160 rpd3Δ_1 rpd3Δ_2 rpd3Δ_3
Cortical Patches 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bud 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bud Neck 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bud Site 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Cell Periphery -2.2 -2.4 -1.4 0.4 0.9 2.0 -0.6 -0.8 0.2 -1.1 -2.1 -3.1 -2.0 -2.4 0
Cytoplasm 0.6 -2.7 -2.1 -4.8 -5.8 -6.3 -6.7 -5.9 -4.8 -0.1 0.1 1.5 0.5 -0.6 1.0
Endoplasmic Reticulum 0 0 0 4.4 5.2 5.2 6.3 5.0 4.2 0 0 0 0 0 0
Endosome 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Golgi 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mitochondria 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Nucleus 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Nuclear Periphery 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Nucleolus 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Peroxisomes 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SpindlePole 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Vacuole 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0


Endocytosis
Temp Actin Patch (Sac6-tdTomato) Cortical Patch (Sla1-GFP) Late Endosome (Snf7-GFP) Vacuole (Vph1-GFP)
37℃
RT
Cell Cycle Omics

CYCLoPs (Oye2-GFP)
Gene / Allele Actin Patch (Sac6-tdTomato) Cortical Patch (Sla1-GFP) Late Endosome (Snf7-GFP) Vacuole (Sac6-tdTomato)
Gene Images
Gene Images
Images are not yet available
Images are not yet available
